Overview of All Actions
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
13-12 C79000-G7076-C526-01
Action Explanation Address
range
Event Instruction Address
Area
Location
R1 ON S i As soon as a registration is
set, step i is activated.
i = step
number
R1 OFF S i As soon as a registration is
set, step i is deactivated.
i = step
number
R1 NC Q,I,M,D* m.n As soon as a registration is
set and the condition
(interlock) is satisfied, the
signal state of the address is
1.
0.0 to
65535.7
R1 SC Q,I,M,D* m.n As soon as a registration is
set and the condition
(interlock) is satisfied, the
address is set to 1 and then
remains set to 1.
0.0 to
65535.7
R1 RC Q,I,M,D* m.n As soon as a registration is
set and the condition
(interlock) is satisfied, the
address is set to 0 and then
remains set to 0.
0.0 to
65535.7
R1 CALLC FB, FC,
SFB, SFC
Block
number
As soon as a registration is
set and the condition
(interlock) is satisfied, the
specified block is called.
R1 ONC S i As soon as a registration is
set and the condition
(interlock) is satisfied, step i is
activated.
i = step
number
R1 OFFC S i As soon as a registration is
set and the condition
(interlock) is satisfied, step i is
deactivated.
i = step
number
Address D: Format: DBi.DBXm.n (i = block number, m = byte address, n = bit address)
For CALL[C] FB/SFB, an instance DB is required.
