09.95

Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
4–40
SINUMERIK 840C (IA)
The change is made in the ASCII editor and must be saved on the hard disk
using the softkey save.
The new colors become active after the next POWER ON.
The value range for each primary color is between 0 and 1000. 1000 is the hig-
hest intensity of color.
Color table POCOCLUT NECOCLUT
Color index
Color Red Green Blue Color Red Green Blue
0 black 0 0 0 black 0 0 0
1 red 1000 0 0 red 1000 0 0
2 green 0 714 0 green 0 714 0
3 blue 0 0 714 blue 0 0 1000
4 yellow 1000 1000 0 yellow 1000 1000 0
5 violet 524 111 397 violet 650
3)
0 650
3)
6 cyan 0 1000 1000 cyan 0 1000 1000
7 white 952 985 952 white 1000 1000 1000
8 grey 444 524 540 grey 444 524 540
9 orange 794 397 16 orange 1000 492 0
10
2)
free
2)
0 0 0 free 0 0 0
11
0)
free
1)
0 0 0 free 0 0 0
12 grey 159 159 159 grey 159 159 159
13 petrol 0 508 444 petrol 0 508 444
14 free 0 0 0 free 0 0 0
15 free 0 0 0 free 0 0 0
Color table POMOCLUT NEMOCLUT
Color index
Color Red Green Blue Color Red Green Blue
0 black 0 0 0 black 0 0 0
1 grey 256 256 256 grey 794 794 794
2 black 0 0 0 white 1000 1000 1000
3 black 0 0 0 white 1000 1000 1000
4 black 0 0 0 white 1000 1000 1000
5 grey 413 413 413 grey 604 604 604
6 grey 698 698 698 grey 698 698 698
7 white 1000 1000 1000 white 1000 1000 1000
8 grey 524 524 524 grey 524 524 524
9 grey 413 413 413 grey 413 413 413
10
2)
free
2)
0 0 0 free
1)
0 0 0
11 free 0 0 0 free 0 0 0
12 grey 698 698 698 grey 159 159 159
13 grey 508 508 508 grey 508 508 508
14 free 0 0 0 free 0 0 0
15 free 0 0 0 free 0 0 0
4 MMC Area Diagnosis
4.4.5 Color mapping lists
01.99
0) As from SW 2 not available for users
1) As from SW 3 = 794
2) As from SW 3 = 720
3) As from SW 3 = 750
