09.95
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
5–53
SINUMERIK 840C (IA)
List contents: The texts for all data are stored in the text lists.
Text lists
Examples: 2040 “Exact stop limit coarse”
2080 “Exact stop limit fine”
5600.0 “No measuring circuit monitoring”
5600.2 “Rounding to whole/half degrees”
List contents: The data type (L = long, C = 8 bits, S = short, etc.) and the display format, any
Semantic lists special treatment and input limits are stored in the semantics lists.
Examples: Data Type Treatment Input limits
160 L 05
164 L 00 ! (write-protected)
168 L “0.0625 5.2 2” [ 2.32]
208 L 72 [ 1.99999999]
The information under “Treatment” is interpreted as follows:
00 1:1 - representation
05 bzw. 07 special treatment or.
-representation
“0.0625 5.2 2”
Unit no.
(the units are in text list tea1unit.106)
5 places, of which 2 are behind the decimal point
Factor for display
List contents: Info lists Explanations for all the data that appear in the information display (key ¼) can
be stored in the information lists.
Example: 2040 “This data is not active until Power On”.
5.10.2 Practical example for user adaptation list display
Problem “PLC machine data 2007 is supplied with the text ”Number of assigned maga-
zine” and with input limits 0 to 4
The user wishes to change this text to the following:
“Number of assigned tool turret”
and the input limits to 1 to 99.
5 Machine Data Dialog (MDD – as from SW 3)
5.10.2 Practical example for user adaptation list display
