09.95
Siemens AG 2001 All Rights Reserved 6FC5197jAA50
4–47
SINUMERIK 840C (IA)
4.4.6 Color settings for monochrome display
4.4.6.1 10” monochrome display (up to SW 4.4) 6FC5 103–0ABV2–0AA0
Introduction The BEDCONF, NECOLLI and NEMOCLUT files have to be edited for improving
the quality of the screen display.
In addition, an anti-reflex filter for the screen has to be installed, order number
6FC5148–0AC01–0AA0.
Color setting BEDCONF
a11111 // BAPLANZ
a11212 // BINPUTMODE
a151MO // BCOLORMONO_DEF
a152NE // BPOSNEG_DEF
a170450000 // BSCREENSAVE
Color setting NECOLLI
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
0
17
0
18
0
19
0
20
0
21
0
22
0
23
0
24
0
25
0
26
0
27
0
28
0
29
0
30
0
31
0
32
0
33
0
34
0
35
0
36
0
37
0
38
0
39
0
40
0
41
0
42
0
43
0
44
0
45
0
46
0
47
0
48
0
49
0
50
0
51
0
52
0
53
0
54
0
55
0
56
0
57
0
58
0
59
0
60
0
61
0
62
0
63
0
64
0
65
14
66
7
67
0
68
0
69
14
70
0
71
7
72
5
73
4
74
0
75
2
76
0
77
4
78
15
79
7
80
11
81
2
82
0
83
4
84
2
85
15
86
15
87
14
88
0
89
12
90
8
91
7
92
1
93
2
94
4
95
3
96
6
97
5
98
12
99
8
100
4
101
7
102
0
103
6
104
3
105
0
106
4
107
0
108
0
109
0
110
0
111
0
112
1
113
8
114
12
115
11
116
11
117
11
118
11
119
0
120
0
121
13
122
0
123
0
124
0
125
0
126
0
127
0
Color setting NEMOCLUT
000
794 794 794
1000 1000 1000
1000 1000 1000
1000 1000 1000
604 604 604
698 698 698
1000 1000 1000
524 524 524
413 413 413
000
000
159 159 159
508 508 508
950 950 950
80 80 80
4.4.6.2 9.5” monochrome display (as from SW 4.5)
In the case of a positive display the basic setting of the ASCII editor must also be
changed.
In file BEDCONF
Entry i 1 2 2207 0//BAEFGCOLOR_DFLT
replace with i 1 2 2207 5//BAEFGCOLOR_DFLT
4 MMC Area Diagnosis
4.4.6 Color settings for monochrome display
