10.94 7 Drive Machine Data (SIMODRIVE Drive MD)
7.1 611A main spindle drive machine data (MSD MD) (SW 3)
7 Drive Machine Data
(SIMODRIVE Drive MD)
7.1 611A main spindle drive machine data (MSD MD) (SW 3)
7.1.1 MSD MD input (SW 3)
The main spindle drive machine data are provided for the purpose of matching the main
spindle drives and the machine tool. If no setting values are specified by the machine
manufacturer or the user, then they must be carefully determined and optimized by the start-
up engineer. The setting values are input by means of menu selection (see section headed
"Machine Data Dialog").
7.1.2 MSD MD (data description - SW 3)
Speed setpoint
1
Default value Lower output limit Upper output limit Units
0 – – rev/min
Active
at once
Display machine data for the present setpoint of the motor speed in rev/min.
Speed actual value
2
Default value Lower output limit Upper output limit Units
0 – – rev/min
Active
at once
Display machine data for the present actual value of the motor speed in rev/min.
Motor voltage
3
Default value Lower output limit Upper output limit Units
– – – V
Active
at once
Display machine data for the present RMS value of the line-to-line motor voltage.
Capacity utilization
4
Default value Lower output limit Upper output limit Units
– – – %
Active
at once
Display machine data for utilization of the main spindle drive. The ratio between torque M
d
and
maximum torque M
dmax
is displayed up to rated speed n
rated
; the ratio between power P and
maximum power P
max
is displayed at speeds above the rated value.
©
Siemens AG 1992 All Rights Reserved 6FC5197- AA50 7–1
SINUMERIK 840C (IA)
