09.95
ï›™
Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
5–40
SINUMERIK 840C (IA)
5.8.4.3 3rd level: File functions
Selection (Example
drive MD axis)
Diagnosis
Machine
data
Start-up
Drive
MD
Axis
(FDD)
File
functions
Explanation Press the Diagnosis, Start-up, Machine data, Drive MD (e.g.), Axis (FDD) and
File functions softkeys to call up the 3rd level file functions display.
Fig. 5.15
Explanation The functions of the softkeys are the same as for the first level. However, the
functions of the two softkeys Save and Load can be expanded.
5 Machine Data Dialog (MDD – as from SW 3)
5.8.4 File functions (sequence of operation – as from SW 3)
