SINUMERIK 840C (IA)
Color table For positive screen display: For negative screen display:
Standard setting
8 tones of grey POMOCLUT NEMOCLUT
Color index
Color Red Green Blue Color Red Green Blue
0 black 0 0 0 black 0 0 0
1 grey 0 0 0 grey 627 627 627
2 black 0 0 0 white 1000 1000 1000
3 black 0 0 0 white 1000 1000 1000
4 black 376 376 376 white 1000 1000 1000
5 grey 376 376 376 grey 627 627 627
6 grey 627 627 627 grey 627 627 627
7 white 1000 1000 1000 white 1000 1000 1000
8 grey 376 376 376 grey 376 376 376
9 grey 0 0 0 grey 376 376 376
10 free 627 627 627 free 627 627 627
11 free 0 0 0 free 0 0 0
12 grey 627 627 627 grey 376 376 376
13 grey 627 627 627 grey 627 627 627
14 free 0 0 0 free 0 0 0
15 free 0 0 0 free 0 0 0
4 MMC Area Diagnosis
4.4.5 Color mapping lists
