09.95

Siemens AG 2001 All Rights Reserved 6FC5197–jAA50
4–45
SINUMERIK 840C (IA)
Example 1 Suppose we want to change the background color of the softkey bar. In the
(with color and table for assigning picture elements to symbolic colors, the symbolic
positive display modes) color code for the softkey bar background is the number 65. In the color mapping
list, a number 8 is entered at position 65. In the color definition table POCOCLUT,
number 8 stands for grey. If we replace the 8 in the color mapping list POCOLLI
by a number 1 the background of the softkey bar becomes red.
Example 2 Suppose we want to change the text color of the alarms. In the table for
(with color and assigning picture elements to symbolic colors, the symbolic color code
positive display modes) for the text color of alarms is the number 75. In the color mapping list, a number 1
is entered at position 75. In the color definition table POCOCLUT, number 1
stands for red. The standard color for alarms is therefore red. If we replace the 1
by a 4 the color of the text of alarms changes to yellow.
Symbolic color
Picture elements
Back-
ground
color
Text
color
Text
back-
ground
Border
color
Border
backgr.
MMC area bar normal 85 84 85 102 90
MMC area bar active 87 86 87 –– ––
Message line for alarms 76 75 76 102 90
Message line for messages 78 77 78 102 90
Message line for comments 80 79 80 102 90
Input cursor blinking –– 100 –– –– ––
Softkey bar normal 65 64 65 102 90
Softkey bar active 67 66 67 –– ––
Borders for 3D display –– –– –– 99
101
––
Symbol for Recall –– 68 –– –– ––
Symbol etc. –– 68 –– –– ––
Symbol for Info –– 105 –– –– ––
Border for active window 112 –– –– 106 ––
Input fields 113 –– –– –– ––
Toggle field writeable 114 –– –– –– ––
Toggle field not writeable 115 –– –– –– ––
Data selector 116 –– –– –– ––
Editor 117 –– –– –– ––
Input values –– 73 88 –– ––
MMC –– 60 97 –– ––
Window header
NCK –– 82 83 –– ––
NC status 89 71 89 102 90
Mode 89 71 89 102 88
Function –– 71 98 –– ––
PC status field –– 81 89 –– ––
Channel status –– 81 89 –– ––
Mode group + channel no. 89 71 89 102 88
Tab. 4.2 Assignment of picture elements to symbolic colors
4 MMC Area Diagnosis
4.4.5 Color mapping lists
