12 Functional Descriptions 07.97
12.32.14 Example on a double-slide turning machine
Protection zone data BITS
Protection zone exists
SR exist.: MD 38764.0 = 1
Monitoring reference OFF
SR 1 - 8: MD 38804.0-7 = 00001000
SR 9 - 16: MD 38844.0-7 = 00000000
SR 17 - 20: MD 38884.0-7 = 00000000
SR 21 - 32: MD 38924.0-7 = 00000000
Machine coordinate system
Machine coord. systems VALUES
Offset vector 2nd machine coordinate system
X coordinate: MD 337 = 0
Y coordinate: MD 338 = 0
Z coordinate: MD 339 = 0
Machine coord. systems BITS
Mirroring vector 2nd mach. coord. system
(X,Y,Z): MD5026.0 - 2 = 001
Axis
-specific data
Coord. assignment of mach. data
1st axis MD 39480 = Abscissa
2nd axis MD 39481 = Applicate
3rd axis MD 39482 = Abscissa
4th axis MD 39483 = Applicate
12–328
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
