12.93 7 Drive Machine Data (SIMODRIVE Drive MD)
7.1.2 MSD MD (data description - SW 3)
Motor code number motor 1
96
Default value Lower input limit Upper input limit Units
101 99 332 –
Active on
Power On
Note:
This machine data is not included in the machine data lists. During start-up in machine data
dialog, the machine data is set or altered as appropriate via the configuration setting.
Input of code number for the motor used. The relevant motor data are stored in the software
and are transferred to machine data MD 159 to MD 175 when the motor code number is
changed. If individual motor data (MD 159 to MD 175) must be changed, then the value 99
(non-Siemens motor) must be entered as the motor code number.
Table of motors:
Order No. Rated
speed
Rated
power
Rated
current
No-load
current
Code
numer
n
rated
in
rev/min
P
rated
in kW
rated
in A
(for T
=100 K)
0
in A
(for T
=100 K)
1PH6101-4NF4- x 1500 3.7 12.5 6.2 101
1PH6101-4NG4- x 2000 4.7 13.7 6.9 102
1PH6103-4NF4- x 1500 5.5 17.9 9.1 103
1PH6103-4NG4- x 2000 7.0 19.4 9.9 104
1PH6105-4NF4- x 1500 7.5 22.5 11.5 105
1PH6105-4NG4- x 2000 9.5 25.3 13.1 106
1PH6107-4NF4- x 1500 9.0 26.9 14.2 107
1PH6107-4NG4- x 2000 11.5 29.8 15.6 108
1PH6131-4NF4- x 1500 9.0 27.2 11.7 109
1PH6131-4NG4- x 2000 12.0 32.1 13.6 110
1PH6133-4NF0- x 1500 11.0 26.7 11.5 111
1PH6133-4NF4- x 1500 11.0 31.3 13.4 112
1PH6133-4NG4- x 2000 14.5 37.5 16.1 113
1PH6135-4NF0- x 1500 15.0 35.0 16.1 114
1PH6135-4NF4- x 1500 15.0 41.3 18.8 115
1PH6135-4NG4- x 2000 20.0 50.6 22.8 116
1PH6137-4NF4- x 1500 18.5 50.2 22.9 117
1PH6137-4NG4- x 2000 24.0 57.8 26.5 118
1PH6138-4NF0- x 1500 22.0 51.5 24.6 119
1PH6138-4NF4- x 1500 22.0 61.0 28.7 120
1PH6138-4NG4- x 2000 28.0 66.1 31.4 121
1PH6161-4NF0- x 1500 22.0 53.5 23.9 122
1PH6161-4NF4- x 1500 22.0 60.8 26.9 123
1PH6161-4NG4- x 2000 28.0 68.1 31.3 124
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 7–13
SINUMERIK 840C (IA)
