09.95 7 Drive Machine Data (SIMODRIVE Drive MD)
7.4.3 Diagnosis/service MD (data description - as from SW 3)
Module order code (as from SW 4)
10100-
10114
10119
1)
Default value Lower output limit Upper output limit Units
0 0 65535 -
Active on
Power on
The "Module order code" machine data contains the selected module in the form of a decimal
code number. In the case of two-axis modules, the data contains two sets of information.
Machine data 10100 to 10114 are assigned to physical addresses 1 to 15.
Power section code (as from SW 4)
10200-
10214
10229
1)
Default value Lower output limit Upper output limit Units
0000 0000 FFFF Hex
Active on
Power on
The "Power section code" machine data contains the required or used amperages for the
selected module according to the hexadecimal code number (see also MD 1106). In the case
of two-axis modules, the data contains two sets of information. Machine data 10200 to 10214
are assigned to physical addresses 1 to 15.
Data version (as from SW 4)
10900
Default value Lower output limit Upper output limit Units
– – – –
Active
Firmware version (as from SW 4)
10901
Default value Lower output limit Upper output limit Units
– – – –
Active
Firmware data (as from SW 4)
10902
Default value Lower output limit Upper output limit Units
– – – –
Active
Hardware configuration (as from SW 4)
10903
Default value Lower output limit Upper output limit Units
– – – –
Active
10903.0 Mixed I/O
10903.1 DCM
1) As from SW 5
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 7–169
