7 Drive Machine Data (SIMODRIVE Drive MD) 09.95
7.4.3 Diagnosis/service MD (data description - as from SW 3)
Status word 1
11004
Default value Lower output limit Upper output limit Units
– 0000 FFFF Hex
Active
after ramp-up
of 611D link
This machine data contains the low-order status bits (bits 0-15) of the cyclical status word at
the interface between SERVO and 611D.
Bit 0 DC link 1 reset
Bit 1 Parking axis setpoint
0 : on
1 : off
Bits 2-4 Assigned to or reserved for internal system functions
Bit 5 Function generator setpoint
0 : on
1 : off
Bit 6 Assigned to or reserved for internal system functions
Bit 7 - SW 4 Ramp-function generator setpoint
0 : on
1 : off
Bit 8 Assigned to or reserved for internal system functions
Bit 9
Bit 10
Bit 11
Ramp-function generator rapid stop setpoint
2nd torque limit setpoint
Speed setpoint smoothing setpoint
0 : off
1 : on
Bits 12-15 Assigned to or reserved for internal system functions
Status word 2
11005
Default value Lower output limit Upper output limit Units
– 0000 FFFF Hex
Active
after ramp-up
of 611D link
This machine data contains the high-order status bits (bits 16-31) of the cyclical status word at
the interface between SERVO and 611D.
Bits 0-2 Set of set parameters 0 to 7
Dec
Bit 3 Motor selection setpoint
0 : star
1 : delta
Bit 4 Assigned to or reserved for internal system functions
Bit 5 - SW 4
Bit 6
Bit 7
Bit 8 - SW 4
Bit 9
Motor switchover
Integrator inhibit setpoint
Pulse enable PLC setpoint
Current controller enable setpoint
Speed controller enable NC setpoint
0 : off
1 : on
7–172 © Siemens AG 1992 All Rights Reserved 6FC5197- AA50
