Mechanical mounting
6.4 Installing the stator in the spindle housing
SIMOTICS M-1FE2 built-in motors
Hardware Installation Manual, 04/2020, A5E50074509B AA
123
Damage to power and sensor cables
The power and sensor cables can be damaged during mounting.
• Position the cables so they are not damaged during mounting.
• Avoid tensions on the cables.
• Do not crush the cables.
Note
The spindle housing sea
ls the cooling thread of the cooling jacket from the exterior.
Tightening torques
For installation, use bolts with at least property class 8.8,
μ
tot
= 0.14.
Preconditions
● All personal protection equipment is available and is worn.
● All production equipment, mounting tools and other equipment for installation are
available and ready for operation.
● All preparatory work for the installation is completed.
Procedure for the vertical installation in the spindle housing
Note
Different shape
The shapes of the cooling jacket
① and the spindle housing ⑤ may differ from those in the
of the axial end-stop ③ and of the internal mandrel ⑦ depend on
the shape of the components and may differ from those in the illustration.
