Description
3.5 Structure of the Article No.
SIMOTICS M-1FE2 built-in motors
56 Hardware Installation Manual, 04/2020, A5E50074509B AA
Description
Position of the article number
1
2
3
4
5
6
7
-
8
9
10
11
12
-
13
14
15
16
-
Z
Number of poles/pairs of poles
8-pole
8
16-pole (1FE218☐ only)
8
Special version
9
H1☐
Motor principle
Asynchronous Al rotor
A
Asynchronous Cu rotor
C
Synchronous APM
L
Winding version
Rated speed differs according to frame
size
☐
Motor protection
Standard protection 2x temperature sensors
(2x Pt1000)
1
Complete motor protection: Standard protection
+ PTC triplet (3x PTC180 in series)
3
Universal protection: Full motor protection + 2x
NTC thermistors (PT3-51-F + NTC K227)
5
Connection
variant
Free cable ends, length 0.5 m; cable outlet of large external diameter
or stator without cooling jacket
0
Free cable ends, length 0.5 m, cable outlet of small external diameter
1
Free cable ends, length 1.5 m; cable outlet of large external diameter
or stator without cooling jacket
2
Free cable ends, length 1.5 m, outlet of small external diameter
3
Special version
9
L1☐
Components (scope of
supply)
Stator and rotor
1
Stator only (individual parts)
2
Rotor only (individual parts)
3
Stator version
Impregnated winding without cooling jacket
A
Cast winding without cooling jacket
B
Impregnated winding with standard cooling jacket
C
Cast winding with standard cooling jacket (on request)
D
Special version
Z
P1☐
Rotor design
Rotor core without sleeve, IDM unmachined
A
Rotor core without sleeve, inner diameter machined ready for installation (on
request)
B
Rotor core with standard sleeve
C
Special version
Z
Q1☐
Version
With Pt1000 temperature sensor - star connection
1
With Pt1000 temperature sensor - star-delta connection
2
Options
Rotor prebalanced (only available for 1FE218.-8L)
T00
