Description
1.7 Nameplates
D4x5
Manual, 05/2009
23
Note
You might need to access the information provided on the side-mounted type plate after the
D4x5 has been mounted. The type plate is located on the right side of the module housing
and is covered by the SINAMICS S120 module. For this reason, we recommend that you
make a note of the serial number of the control unit prior to assembly.
Note
The information contained in each field of the type plate on your actual control unit may differ
from that presented in this manual (for example, a later product version, approvals and
marks that have not yet been earned, etc., may be shown).
MAC addresses
A second type plate for the MAC addresses of the two Ethernet interfaces is attached to the
front of the device. You see this type plate when you open the front cover of the control unit.
0$&DGGUHVVRI;
0$&DGGUHVVRI;
+:YHUVLRQ
2UGHUQXPEHU
Figure 1-6 MAC addresses
