Page #39 background imageLoading...
Page #39 background image
Interfaces
3.3 Ethernet interfaces
D4x5
Manual, 05/2009
39
Features
Table 3- 3 X100 - X103 (SIMOTION D425, D435) or X100 – X105 (SIMOTION D445/D445-1)
Features Type
Connector type DRIVE-CLiQ plug
Cable type DRIVE-CLiQ standard (inside the control cabinet)
Cable type MOTION CONNECT (outside the control cabinet)
Maximum cable length 100 m
Blanking cover See FAQ FAQ link
(http://support.automation.siemens.com/WW/view/en/31236839)
DRIVE-CLiQ pin assignment
Table 3- 4 DRIVE-CLiQ interface (X100 - X103 or X100 – X105)
PIN Signal name Signal type Meaning
1 TXP O Transmit data +
2 TXN O Transmit data -
3 RXP I Receive data +
4 ---- ---- Reserved, do not use
5 ---- ---- Reserved, do not use
6 RXN I Receive data -
7 ---- ---- Reserved, do not use
8 ---- ---- Reserved, do not use
A + (24 V) VO Power supply for DRIVE-CLiQ, 450 mA maximum
B M (0 V) VO Ground to 24 V
Signal type: I = Input; O = Output; VO = Voltage Output
Additional references
SINAMICS S120 Control Units and Additional System Components
Manual
SINAMICS S120 Booksize Power Units
Manual
SINAMICS S120 for AC Drives
Manual
SINAMICS S120
commissioning manual
Terminal Modules TM15 and TM17 High Feature
commissioning manual
Supplementary SINAMICS System Components for SIMOTION
Manual
For order numbers, refer to the list of references (separate document).
3.3 Ethernet interfaces
Interfaces for connection to Industrial Ethernet.
Industrial Ethernet is a communication network with a transmission rate of 10/100 Mbit/s.
