Interfaces
3.4 Digital inputs/digital outputs
D4x5
42 Manual, 05/2009
3.4 Digital inputs/digital outputs
3.4.1 Features
Interface features
Sensors and actuators can be connected to the X122, X132 connector via digital inputs and
outputs.
Table 3- 7 Interfaces X122 and X132
Features Type
Connector type Micro Combicon
Connection possibility Up to 0.25 mm
2
Max. current carrying capacity (ground) 4 A
Position of connectors
'LJLWDOLQSXWV
3LQ
'LJLWDOLQSXWVGLJLWDORXWSXWV
3LQDQG
;;
Figure 3-3 Digital inputs and digital inputs/outputs (interfaces X122 and X132)
