Description
1.7 Nameplates
D4x5
22 Manual, 05/2009
CAUTION
SIMOTION D445-1 must be operated with a double fan/battery module for heat dissipation.
Without this module, the Control Unit will not start up and cannot be commissioned.
Information on how to install the double fan/battery module can be found in "Spare
Parts/Accessories", Section
Installing the fan/battery module (Page 70).
Note
SIMOTION D445-1 comes with pre-assembled spacers. These can be removed if
necessary.
1.7 Nameplates
Side-mounted type plate
The following figure shows you all the information included in the type plate located on the
side of the unit.
0RGXOHGHVLJQDWLRQ
2UGHUQXPEHU
6HULDOQXPEHU
+:YHUVLRQ
Figure 1-5 Type plate
