Siemens SIMOTION D425

Spare parts/accessories
6.5 Terminal module TM31
D4x5
74 Manual, 05/2009
Additional references
You will find detailed information about the CBE30 in the
●
Supplementary SINAMICS System Components for SIMOTION Manual
●
SIMOTION D4x5 Commissioning and Hardware Installation Manual
●
SIMOTION Communication System Manual
6.5 Terminal module TM31
Features of the TM31
With the TM31 Terminal Module, the number of available digital inputs/digital outputs and the
number of analog input/analog outputs within a drive system can be expanded. The TM31 is
connected by means of DRIVE-CLiQ. It has two DRIVE-CLiQ interfaces for this purpose.
The TM31 contains the following terminals:
Table 6- 3 Interface overview of the TM31
Interface Quantity
Digital inputs 8
Bidirectional inputs/outputs 4
Relay outputs with changeover contact 2
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
CAUTION
The 50 mm clearances above and below the components must be observed.
Additional references
You will find detailed information about the TM31 in the
●
Supplementary SINAMICS System Components for SIMOTION Manual
●
SIMOTION D4x5 Commissioning and Hardware Installation Manual
