Spare parts/accessories
6.4 CBE30 communication board
D4x5
Manual, 05/2009
73
Table 6- 2 Overview of TB30 interface
Interface Quantity
Digital inputs 4
Digital outputs 4
Analog inputs 2
Analog outputs 2
CAUTION
The Terminal Board may only be inserted and removed when the D4x5 Control Unit and
the TB30 Terminal Board are de-energized.
Additional references
You will find detailed information about the TB30 Terminal Board in the
●
Supplementary SINAMICS System Components for SIMOTION
Manual
●
SIMOTION D4x5
Commissioning and Hardware Installation Manual
6.4 CBE30 communication board
Features of the CBE30
The Ethernet communication board (CBE30) for SIMOTION D4x5 enables connection to a
PROFINET IO network. The SIMOTION D4x5 then assumes the role of a PROFINET IO
Controller and can offer the following functions:
● PROFINET IO Controller, I-Device (also controller and device simultaneously)
● 100 Mbit/s full duplex/autocrossing
● Supports real-time classes of PROFINET IO:
– RT (Real Time)
– IRT (Isochronous Real Time)
The CBE30 has a X1400 interface with an integral 4-port switch based on PROFINET ASICs
ERTEC400.
CAUTION
The CBE30 may only be inserted and removed when the D4x5 Control Unit and CBE30 are
in a de-energized state.
