Interfaces
3.5 Power supply
D4x5
46 Manual, 05/2009
● DI/DO9 to 11 and DI/DO13 to 15 can be used as high-speed inputs of measuring inputs
or for external zero marks.
The assignment of the inputs is not fixed, and the special use is activated in the
SIMOTION SCOUT engineering system.
● All eight digital inputs/outputs can be used as user-addressable inputs or as homing
inputs.
When the DI/DO are assigned as digital outputs, they can be used as follows:
● Use as user-addressable outputs
● Use as high-speed DO
● Use as high-speed outputs of output cams
Note
Shielded cables are required when connecting probes or external zero marks for optimal
noise immunity.
Additional references
For information on configuring the DI/DO as user-addressable I/O, measuring inputs or
outputs of output cams, see the
SIMOTION D4x5
Commissioning and Hardware Installation
Manual.
For information on the configuration and function of the measuring input, output cam, and
cam track technology objects, refer to the
SIMOTION Output Cams and Measuring Inputs
Function Manual.
3.5 Power supply
This interface is provided exclusively for connection of the external power supply.
Note
When using external power supplies (e.g. SITOP), the ground potential must be connected
with the protective ground terminal (PELV).
Features of the interface
Table 3- 10 Interface X124
Features Type
Connector type Combicon
Connection possibility Up to 2.5 mm
2
Max. current carrying capacity 10 A
Maximum cable length 10 m
