6.11 Controller Extension CX32
Features of the CX32 (Controller Extension)
The CX32 is a module in SINAMICS S120 booksize format and supports scaling of the drive-
side computing performance of the SIMOTION D435, D445, and D445-1 Control Units.
Each CX32 can control up to 6 additional servo, 4 vector or 8 V/
f
axes.
Quantity structures
If one or more CX32 modules are being used on a SIMOTION D435 or D445/D445-1, the
number of drives that can be used on the SINAMICS Integrated is reduced by one. This
gives the following quantified volumes:
SIMOTION V4.1SINAMICS V2.5
Table 6- 7 SIMOTION V4.1/SINAMICS V2.5 quantified volume
SINAMICS
Integrated
1. CX32 2. CX32 3. CX32 4. CX32
SERVO D435 5+1 (5 drives+1
ALM
1)
)
6+1 6+1 ----- -----
SERVO
D445/D445-1
5+1 6+1 6+1 6+1 6+1
VEKTOR D435 3+1 4+1 4+1 ----- -----
VECTOR
D445/D445-1
3+1 4+1 4+1 4+1 4+1
1)
ALM = Active Line Modules; Basic Line Modules (BLM), and Smart Line Modules (SLM)
can also be used.
SIMOTION V4.0 HF2/ SINAMICS V2.4
Table 6- 8 SIMOTION V4.0 HF2/ SINAMICS V2.4 quantified volume
SINAMICS
Integrated
1. CX32 2. CX32 3. CX32 4. CX32
SERVO D435 5+1 (5 drives+1
ALM
1)
)
6+0 6+0 ----- ------
SERVO D445 5+1 6+0 6+0 6+0 -----
VEKTOR D435 3+1 4+0 4+0 ----- -----
VEKTOR D445 3+1 4+0 4+0 4+0
