6.11 Controller Extension CX32
D4x5
80 Manual, 05/2009
1) ALM = Active Line Modules; Basic Line Modules (BLM), and Smart Line Modules (SLM)
can also be used.
Note
Mixed operation of servo and vector-controlled drives
Mixed operation of servo and vector-controlled drives is not possible on a CX32. Therefore,
drives on a CX32 must be operated in servo or in vector mode only. As with the SIMOTION
D4x5, mixed operation of servo and V/f-controlled drives is possible on a CX32.
V/f-controlled drives
A maximum of 8 V/f-controlled drives are supported by each CX32.
The CX32 has the following interfaces:
● 4 DRIVE-CLiQ (X100 – X103)
● 4 digital inputs and 4 digital inputs/outputs (X122)
● Power supply (X124)
CAUTION
The cooling clearances of 80 mm above and below the components must be observed.
Additional references
You will find detailed information about the CX32 in the
●
Supplementary SINAMICS System Components for SIMOTION
Manual
●
SIMOTION D4x5
Commissioning and Hardware Installation Manual
