Siemens SIMOTION D425 User Manual

Description
1.9 CompactFlash card
D4x5
Manual, 05/2009
25
1.9 CompactFlash card
1.9.1 Usage and function of the CompactFlash Card
The Compact Flash card (CF card) is inserted in the CF plug-in slot (X109 interface).
5HFHVVHGJULSRIWKH&RPSDFW)ODVKFDUG
%ODQNLQJSODWH
Figure 1-7 Slot for Compact Flash card
The CF card does not extent beyond the housing. An ergonomic recessed grip enables the
CF card to be removed.
Properties of the CF card
The CF card is mandatory for operation of the SIMOTION D4x5. The CF card is not supplied
with the SIMOTION D4x5 and must be ordered separately.
