Operator control (hardware)
2.3 LED displays
D4x5
Manual, 05/2009
35
LED Meaning
DP2 ... indicates the state of the PROFIBUS DP2/MPI interface.
OPT ... indicates the state of the option module (if available).
Note
While the SIMOTION D4x5 is ramping up, all LEDs are briefly illuminated in yellow.
Additional information
You can carry out a detailed diagnosis using a PG/PC and the Engineering System.
Information on the diagnosis via LED displays can also be found in the Commissioning and
Hardware Installation Manual
SIMOTION D4x5
and in the Online Help of this chapter via the
link under menu instructions.
