Siemens SIMOTION D425 User Manual

Technical Data
4.1 Technical data D4x5
D4x5
54 Manual, 05/2009
Dimensions and weight
Table 4- 3 Dimensions and weight of a SIMOTION D4x5
Parameter SIMOTION D425/D435 SIMOTION D445 SIMOTION D445-1
Dimensions
W x H x D [mm]
(max. expansion)
• excl. fastening using
spacers, no fan or
battery modules
• incl. fastening using
spacers, no fan or
battery modules
• 50 x 380 x 230
• 50 x 380 x 270
• Not possible
(spacers always
required)
• 50 x 380 x 270
• 50 x 380 x 230
• 50 x 380 x 270
Weight [g]
- Without packaging
- With packaging
Approx. 2600
Approx. 3100
Approx. 3500
Approx. 4000
Approx. 3100
Approx. 3600
Ambient conditions
Table 4- 4 D4x5 environmental requirements
Parameter Values
Permissible ambient temperature
• Storage and transport
• Operation
• -40° C to +70° C
• 0 °C to +55 °C up to 2000 m above sea level
Starting at an altitude of 2000 m, the maximum
ambient temperature decreases by 7 °C every
1000 m
Permissible relative humidity
(without condensation)
5 % ... 95 %
Installation altitude Up to 5000 m above sea level
Organic/biological influences
• Storage
• Transport
• Operation
• Class 1B1 according to EN 60 721-3-1
• Class 2B1 according to EN 60 721-3-2
• Class 3B1 according to EN 60 721-3-3
Pollution degree 2 according to EN 60 664-1
Degree of protection to EN 60529 (IEC 60529) IP20
Atmospheric pressure 700...1060 hPA
