Installing
3.4 Mounting the Power Modules
Power Module PM240-2
Hardware Installation Manual, 01/2020, A5E33294624B AL
37
Mounting the shield plate, FSA ... FSC - PT Power Module
Note
Built-in devices and PT Power Modules
The shield plates are mounted in the same way for PT and IP20 devices.
Upper shield plate
The top shield plate is not supplied with the converter. You need it as a shield support when
you conne
ct an external braking resistor.
Braking resistor (Page 133)
EMC connecting bracket
The EMC connecting bracket is
only supplied with converters with integrated filter.
