Technical data
6.4 200 V converters
Power Module PM240-2
82 Hardware Installation Manual, 01/2020, A5E33294624B AL
Table 6- 6 PM240-2, PT, frame size C, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PB21-8UL0
6SL3211-1PB21-8AL0
LO base load power 4 kW
1 AC LO base load input current 43.0 A
3 AC LO base load input current 22.8 A
LO base load output current
17.5 A
HO base load power
3 kW
1 AC HO base load input current 37.5 A
3 AC HO base load input current
17.7 A
HO base load output current
13.6 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820 (50 A)
50 A
Power loss
0.18 kW
1)
Required cooling air flow
18.5 l/s
Weight without filter
5.9 kg
Weight with filter
6.2 kg
1)
approx. 0.09 kW through the heat sink
Table 6- 7 PM240-2, IP 20, frame size C, 200 V … 240 V 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PC22-2UL0
6SL3210-1PC22-2AL0
6SL3210-1PC22-8UL0
6SL3210-1PC22-8AL0
LO base load power
5.5 kW
7.5 kW
LO base load input current
28.6 A
36.4 A
LO base load output current
22.0 A
28.0 A
HO base load power
4 kW
5.5 kW
HO base load input current 22.8 A 28.6 A
HO base load output current 17.5 A 22.0 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820 (50 A)
50 A
3NA3820 (50 A)
50 A
Power loss 0.2 kW 0.26 kW
Required cooling air flow 18.5 l/s 18.5 l/s
Weight without filter
5.0 kg
5.0 kg
Weight with filter
5.2 kg
5.2 kg
