The following user-specic les are required. You can use the sample les as template:
File Meaning
"sljkcong.ini" conguration le File in which the traversing keys are congured.
Text le "oem_sljk_xxx.ts" File for labeling traversing keys in a foreign language, xxx =
language code
"sljkcong.ini" conguration le
Entries Meaning
[State_1] Labeling type - changed via the PLC.
ParamText_x_y Text of the traversing key that is made up of parameters.
Two-line labeling is possible, whereby max. ve characters are possible per line.
x: Species the position of the key within the row (2 to 7).
y: Species the key row (1 or 2).
%m1 The machine axis name of the rst axis is referenced and displayed as text.
The current active axis number is read out from data block DB10. The
name from the machine data is determined via this index.
%n Denes the position in the text for the line break.
%a1 The alias axis name of the rst axis is referenced and displayed as text. The
current active axis number is read out from data block DB10. The name
from the "oem_sljk_eng.ts" text le is determined via this index.
TextId_x_y Text of the traversing key that is read from the text le (target language text).
Picture_x_y File name of the icon to be displayed.
The les with the icons must be located in the following directories: /oem/sinumer‐
ik/hmi/ico and
depending on the resolution of the subdirectories:
/ico640
/ico800
/ico1024
/ico1280
Procedure
1. Copy the "sljkcong.ini" conguration le from the folder
/siemens/sinumerik/hmi/template/cfg
2. Place the copy into the folder /oem/sinumerik/hmi/cfg
or /user/sinumerik/hmi/cfg
3. Open the copy in the Editor and dene the traversing key labeling.
Example of a "sljkcong.ini" conguration le
12 axes are dened in the example, with text for softkey 1 and softkey 2, as well as an image on
softkey 3 and softkey 4.
[Settings]
FileType = INI
Commissioning
8.1SINUMERIK Operate
Handheld Terminal HT 8
116 Equipment Manual, 02/2024, A5E52918633B AA
