8.1.4 Con󹪝guring the function display at user-speci󹪝c keys (U keys)
Function
Active functions can be displayed at the con󹪝gurable user keys via the PLC. For instance, small
LEDs can be emulated on the softkeys.
You con󹪝gure the function in the "slckcpf.ini" 󹪝le.
Interface signals
The PLC bits are in the output image of the PLC-HT 8 interface and are analog to those in the input
image.
Signals to the MCP1 (or MCP2)
Interface PLC → HT8
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
AB n + 1  U4 U3  U2 U1  
AB n + 4 U9 U10 U11 U12 U13 U14 U15 U16
AB n + 5  U8 U7 U6 U5   
Adapt the display in the "slckcpf.ini" 󹪝le
Section Description
UserKeyLEDIcon
Name of the icon 󹪝le.
Standard entry: led_green.png
OFF
Deactivates the icon display.
PRESSED
Displays the active functions by pressing
down the softkey.
UserKeyLEDIconAlignment
Speci󹪝es the position of the icon.
Standard position: AlignLeft | AlignTop
Horizontal and vertical alignments can be combined. The two
names are separated by the "|" character.
The following alignments are possible:
AlignLeft Left
AlignRight Right
AlignHCenter Horizontal, center
AlignTop Top
AlignBottom Bottom
AlignVCenter Vertical, center
UserKeyLEDMap
Speci󹪝es the start address of the output image.
Entries can be made in the following form: "DBx.DBBy", "ABx",
"MBx".
Default setting: The start address is determined using
DB7MCP1Out (or MCP2Out).
Commissioning
8.1SINUMERIK Operate
Handheld Terminal HT 8
122 Equipment Manual, 02/2024, A5E52918633B AA
