Siemens SINUMERIK 804D sl Equipment Manual

Note
The PFH
d
value only applies if the technical properties of the acknowledgment button and the
quantitative conditions speci󹪝ed here (e.g. operating period) are observed. Mechanical
switches such as the acknowledgment button are subject to wear due to use.
The wear-related service life should be determined on the basis of typical operating actions and,
if possible, compared with values obtained in practice.
10.2 Connection module Basic PN
Safety
Safety class III according to IEC 60536
Degree of protection accord‐
ing to EN 60529
IP54
Approvals CE / cULus
Electrical data
Input voltage 24 VDC (via X3 connector)
Current carrying capacity Enabling button contacts (X20 connector) max. each 0.5 A / 2-chan‐
nel
Emergency stop button contacts (X21 con‐
nector)
max. each 0.5 A / 2-chan‐
nel
Max. power consumption Connection module without external load‐
ing
0.3 A
Panel (HT8) 0.85A
3 status signals (X7 and X21) 1.5 A (load-dependent
max. each 0.5 A)
Total (with HT8, 3 status signals): 2.35 A
Max. total
power consumption
56.4 W
Mechanical data
Dimensions Height (without holder for termi‐
nating connector):
66 mm
Width:
165 mm
Length:
166 mm
Weight 0.75 kg
Fall height, max. 1.20 m
Note
Information about the climatic and mechanical environmental conditions is contained in the
associated section under:
"General notes and interconnection" → "Operational planning".
Technical speci󹪝cations
10.2Connection module Basic PN
Handheld Terminal HT 8
Equipment Manual, 02/2024, A5E52918633B AA 133
