Ambient climatic conditions
Climate class according to EN
60721‑3-3
Better than class 3K3
Temperature 0...55° C (without derating)
Installation altitude Up to 1000 m without derating
From 1000 m to 3000 m with linear ambient temperature de‐
rating, -0.5 K per 100 m
Relative humidity 5 ... 95% (no condensation)
Oil mist, salt mist, ice formation, con‐
densation, dripping water, spraying
water, splashing water and water jets
Not permitted
Biological, chemical, electrical and mechanical in󹪞uences, pollutants
Biological environmental conditions Class 3B1 according to EN 60721-3-3:
Mold, mold growth, slime, rodents, termites and other animal
vermin are not permissible.
Chemically active environmental con‐
ditions
Class 3C1 according to EN60721‑3‑3
Mechanically active environmental
conditions
Class3M1 according to EN60721‑3‑3:
Conductive dust not permissible.
Classi󹪝cation of the mechanical
environment
3M3 for components on the machine
3M1/3M2 for components in the control cabinet
Vibration test in operation According to IEC60068-2-6 test Fc (sinusoidal)
• 10…57 Hz: 0.075 mm de󹪞ection amplitude
• 57…150 Hz: 1 g acceleration amplitude
• 10 frequency cycles per axis
Shock test in operation According to IEC60068-2-27 test Ea (half-sine)
• 5 g peak acceleration
• 30 ms duration
• 3 shocks in all three axes in both directions
Degree of contamination 2 (only use indoors)
EMC conducted / radiation Class C2 according to EN61800-3
Note
The user must consider radio interference for the complete system. Particular attention should
be paid to cabling. Please contact your sales representative for assistance and support.
Note
In a residential environment, this product can cause high-frequency interference, which may
make interference suppression measures necessary.
Have the installation and commissioning with appropriate radio interference suppression
measures performed by quali󹪝ed personnel.
General information and networking
4.1Application planning
Handheld Terminal HT 8
28 Equipment Manual, 02/2024, A5E52918633B AA
