Pin Signal Signal type Meaning
A4 STOP -13
K
Emerg. Stop circuit 2
A5 STOP -23 Emerg. Stop circuit 1
A6 P24 VI +24 V power supply
Pin Signal Signal type Meaning
B1 IDENT_N - Box ID transfer -
B2 ENABLE 2-
O
Enabling button channel 2, digital
B3 ENABLE 1- Enabling button channel 1, digital
B4 STOP -14
K
Emerg. Stop circuit 2
B5 STOP -24 Emerg. Stop circuit 1
B6 M24 VI External ground
Interfaces
6.2Description
Handheld Terminal HT 8
Equipment Manual, 02/2024, A5E52918633B AA 97
