808d-mte40 - 100 0 32000 7/2 M
808d-mte60 - 100 0 32000 7/2 M
Description: The data limits the maximum number of special functions over and above the predefined
functions (such as sine, cosine, etc.) which can be used in
● cycle programs
● compile cycle software.
The function names are entered in the global NCK dictionary and must not conflict with
the names that already exist.
The SIEMENS cycle package contains special functions that are taken into account by
the default setting of the MD.
The data are stored in unbuffered memory. Approximately 150 bytes are required for
each special function for management purposes.
Related to:
MD18180 $MN_MM_NUM_MAX_FUNC_PARAM
(Number. of additional parameters)
18180 MM_NUM_MAX_FUNC_PARAM N02 V2
- Number of additional parameters for cycles according to MD 18170 DWORD PowerOn
-
808d-me42 - 1000 0 32000 0/0 S
808d-me62 - 1000 0 32000 0/0 S
808d-te42 - 1000 0 32000 0/0 S
808d-te62 - 1000 0 32000 0/0 S
808d-mte40 - 1000 0 32000 7/2 M
808d-mte60 - 1000 0 32000 7/2 M
Description: Defines the maximum number of parameters required for the special functions in
● cycle programs
● compile cycle software.
50 parameters are required for the special functions of the SIEMENS cycle package,
software version 1.
The data are stored in unbuffered memory. 72 bytes of memory are reserved for each
parameter.
Related to:
MD18170 $MN_MM_NUM_MAX_FUNC_NAMES
(Number of special functions)
18190 MM_NUM_PROTECT_AREA_NCK N12, N02, N06,
N09
A3
- Number of control-specific protection areas (SRAM) DWORD PowerOn
-
808d-me42 - 10 0 10 1/1 M
808d-me62 - 10 0 10 1/1 M
808d-te42 - 10 0 10 1/1 M
808d-te62 - 10 0 10 1/1 M
808d-mte40 - 0 0 10 1/1 M
808d-mte60 - 0 0 10 1/1 M
Description: This machine data defines how many control-specific protection areas have been created.
Related to:
MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN (number of channel-specific protection areas)
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 101
