MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE (number of simultaneously active protection
areas)
References:
/FB/, A3, "Axis Monitoring, Protection Areas"
18204 MM_NUM_CCS_TDA_PARAM N02, N09 FBWsl
- Number of Siemens OEM tool data (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 10 2/2 M
808d-me62 - 0 0 10 2/2 M
808d-te42 - 0 0 10 2/2 M
808d-te62 - 0 0 10 2/2 M
808d-mte40 - 0 0 10 0/0 S
808d-mte60 - 0 0 10 0/0 S
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 2=1 ('H4'), is set:
User or OEM data of the tools.
Number of Siemens OEM TDA (=tool-specific) data (standard format Int).
See also: MD18094 $MN_MM_NUM_CC_TDA_PARAM, MD18082 $MN_MM_NUM_TOOL
Buffered user memory is used
18205 MM_TYPE_CCS_TDA_PARAM N02, N09 FBWsl
- Type of Siemens OEM tool data (SRAM) DWORD PowerOn
-
808d-me42 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2 M
808d-me62 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2 M
808d-te42 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2 M
808d-te62 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2 M
808d-mte40 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 0/0 S
808d-mte60 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 0/0 S
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 2=1 ('H4'), is set:
User or OEM data in the tool management.
Type of tool-specific Siemens user data configured by MD18204 $MN_MM_NUM_CCS_TDA_PARAM.
Each parameter can be assigned its own type. The permissible types are
Type Value of the machine data
(See types of the NC language)
----------------------------------------------------------------
BOOL 1
CHAR 2
INT 3
REAL 4
STRING 5 (permits identifiers up to 31 characters long)
AXIS 6
FRAME not defined
See also: MD18204 $MN_MM_NUM_CCS_TDA_PARAM, MD18082 $MN_MM_NUM_TOOL
Buffered user memory is used. A change in value leads to reconfiguration of the
buffered memory.
Machine data
3.2 General machine data
Parameter Manual
102 List Manual, 01/2017
