Bit 2 = 1 :
Prog-Event after OP reset causes block change despite read-in disable
Bit 3 = 1 :
Prog-Event after ramp-up causes block change despite read-in disable
Bit 4 = 1 :
Prog-Event after 1st start after search run causes block change despite read-in disable
Bit 5 = 1 :
Safety-Prog-Event during ramp-up causes block change despite read-in disable
Corresponds to:
MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK
MD20106 $MC_PROG_EVENT_IGN_SINGLEBLOCK
MD20108 $MC_PROG_EVENT_MASK
MD20192 $MC_PROG_EVENT_IGN_PROG_STATE
MD20193 $MC_PROG_EVENT_IGN_STOP
20108 PROG_EVENT_MASK N01 TE3, K1
- Setting of event-driven programm calls DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2 M
Description: The user program is called via the following search path:
1. /_N_CUS_DIR/_N_PROG_EVENT_SPF
2. /_N_CMA_DIR/_N_PROG_EVENT_SPF
3. /_N_CST_DIR/_N_PROG_EVENT_SPF
The safety program has to be available in the following location:
1. /_N_CST_DIR/_N_SAFE_SPF
Corresponds to:
MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK
MD20106 $MC_PROG_EVENT_IGN_SINGLEBLOCK
MD20107 $MC_PROG_EVENT_IGN_INHIBIT
MD20192 $MC_PROG_EVENT_IGN_PROG_STATE
MD20193 $MC_PROG_EVENT_IGN_STOP
20109 PROG_EVENT_MASK_PROPERTIES N01 K1
- Properties of Prog-Events DWORD PowerOn
-
808d-me42 - 0x01 0 0x1 2/2 M
808d-me62 - 0x01 0 0x1 2/2 M
808d-te42 - 0x01 0 0x1 2/2 M
808d-te62 - 0x01 0 0x1 2/2 M
808d-mte40 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x1 2/2 M
808d-mte60 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x1 2/2 M
Description: Parameterization of additional properties of the event-controlled program calls (in
short,
Prog-Event),
that
is, the MD20108 $MC_PROG_EVENT_MASK is further parameterized.
Bit 0 = 1 :
An ASUB started from channel status RESET does not result in a Prog-Event.
Machine data
3.3 Channel-specific machine data
Parameter Manual
126 List Manual, 01/2017
