Siemens SINUMERIK 808D Parameter Manual

20110 RESET_MODE_MASK C11, C03 F2, K6, M3, TE4, W5, B3, K5,
M1, G2, K1,
K2, P1, S1, W1, 2.4,
2.7
- Definition of basic control settings after reset/PP end DWORD Reset
-
808d-me42 - 0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045...
0 0x17FFFF 1/1 M
808d-me62 - 0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045...
0 0x17FFFF 1/1 M
808d-te42 - 0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045...
0 0x17FFFF 1/1 M
808d-te62 - 0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045,
0x4045, 0x4045...
0 0x17FFFF 1/1 M
808d-mte40 - 0x1, 0x1, 0x1, 0x1,
0x1, 0x1, 0x1, 0x1...
0 0x17FFFF 1/1 M
808d-mte60 - 0x1, 0x1, 0x1, 0x1,
0x1, 0x1, 0x1, 0x1...
0 0x17FFFF 1/1 M
Description: Definition of the initial setting of the control after ramp-up and at reset/end-of-
part-program with regard to the G codes (in particular the active plane and the
settable work offset), tool length offset and transformation by setting the following
bits:
Bit 0: Reset mode
Bit 1: Suppress aux. funct. output on tool selection
Bit 2: Select reset response after power-on (e.g. tool offset)
Bit 3: Select reset response after end of test mode with regard to active tool offsets.
Bit 4: Reserved
Bit 5: Reserved
Bit 6: Reset response "Active tool length offset"
Bit 7: Reset response "Active kinematic transformation"
Bit 8: Reset response "Coupled-motion axes"
Bit 9: Reset response "Tangential correction"
Bit 10: Reset response "Synchronous spindle"
Bit 11: Reset response "Revolutional feedrate"
Bit 12: Reset response "Geo axis replacement"
Bit 13: Reset response "Master value coupling"
Bit 14: Reset response "Basis frame"
Bit 15: Reset response "Electronic gearbox"
Bit 16: Reset response "Master spindle"
Bit 17: Reset response "Master toolholder"
Bit 18: Reset response "Reference axis for G96/G961/G962"
Bit 19: Reserved "Adjustable software limit switch ineffective"
Bit 20: Reset response "$P_USEKT"
Bits 4 to 11, 16 and 17 are only evaluated for bit 0 = 1.
Meaning of the individual bits:
Machine data
3.3 Channel-specific machine data
Parameter Manual
List Manual, 01/2017 127
