20112 START_MODE_MASK C03 K6, M3, K5, M1, K1, K2, P1, S1,
W1
- Definition of basic setting of control after part program start DWORD Reset
-
- - 0x400, 0x400, 0x400,
0x400, 0x400, 0x400,
0x400, 0x400...
0 0x7FFFF 1/1 M
Description: The initial setting of the control at the start of the part program with respect to G
codes (in particular, current plane and settable work offset), tool length offset,
transformation, and axis couplings is defined by setting the following bits:
Bit 0: Start mode
Bit 1: Suppress aux. funct. output on tool selection
Bit 2: Not assigned, but reserved (see corresponding bit in RESET_MODE_MASK)
Bit 3: Not assigned, but reserved (see corresponding bit in RESET_MODE_MASK)
Bit 4: Start response for G code "Current plane"
Bit 5: Start response for G code "Settable work offset"
Bit 6: Start response for "Active tool length offset"
Bit 7: Start response for "Active kinematic transformation"
Bit 8: Start response for "Coupled-motion axes"
Bit 9: Start response for "Tangential correction"
Bit 10: Start response for "Synchronous spindle"
Bit 11: Not assigned, but reserved (see corresponding bit in RESET_MODE_MASK)
Bit 12: Start response for "Geo axis replacement"
Bit 13: Start response for "Master value coupling"
Bit 14: Not assigned, but reserved (see corresponding bit in RESET_MODE_MASK)
Bit 15: Not assigned, but reserved (see corresponding bit in RESET_MODE_MASK)
Bit 16: Start response for "Master spindle"
Bit 17: Start response for "Master toolholder"
Bit 18: Start response for "Reference axis for G96/G961/G962"
Bit 19: Reserved "Adjustable software limit switch ineffective"
Bit 20: Reserved "$P_USEKT reset response"
Meaning of individual bits:
Bit 0 = 0:
The bits 8 (TRAIL), 10 (COUP), bit 13 (LEAD) and bit 15 (EG) are evaluated on part
program start and event-driven program calls of the Progevent ASUB
Bit 0 = 1:
The bits 8 (TRAIL), 10 (COUP), bit 13 (LEAD) and bit 15 EG) are evaluated only on part
program start
Bit 1 = 0:
Auxiliary function output (D, T, M, DL) to PLC on tool selection according to the
following MDs: MD20120 $MC_TOOL_RESET_VALUE, MD20130 $MC_CUTTING_EDGE_RESET_VALUE,
MD20121 $MC_TOOL_PRESEL_RESET_VALUE, and MD22550 $MC_TOOL_CHANGE_MODE.
Note:
If tool or magazine management is active, only auxiliary functions D and DL are
output.
Bit 1 = 1:
Suppress auxiliary function output to PLC on tool selection.
Bit 1 is not relevant if tool or magazine management is active.
Bit 2 : Reserved (reset response after power-on)
Bit 3 : Reserved (end of test mode)
Machine data
3.3 Channel-specific machine data
Parameter Manual
132 List Manual, 01/2017
