Bit 31 = 1: Enable interrupt 32 (system interrupt, reserved)
NOTICE:
System ASUBs started by system interrupts may contain traversing motions.
Related to:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
20117 IGNORE_SINGLEBLOCK_ASUP C01 K1, Z1
- Execute interrupt program completely despite single block DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7FFFFFFF 2/2 M
Description: In spite of the set single-block processing mode, the assigned ASUB with the set bit
is executed for the interrupt.
Bit 0 = 1: Enable interrupt 1 (user interrupt)
Bit 1 = 1: Enable interrupt 2 (user interrupt)
...
Bit 7 = 1: Enable interrupt 8 (user interrupt)
Bit 8 = 1: Enable interrupt 9 (system interrupt, reserved)
Bit 9 = 1: Enable interrupt 10 (system interrupt, reserved)
Bit 10 = 1: Enable interrupt 11 (system interrupt, reserved)
...
Bit 31 = 1: Enable interrupt 32 (system interrupt, reserved)
NOTICE:
System-ASUBs started by system interrupts may contain traversing motions.
Note:
The machine data is only active with single block SBL1.
Related to:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
20120 TOOL_RESET_VALUE C03 K1, W1
- Tool with length compens. during runup (reset/part program end). DWORD Reset
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1 M
Description: Definition of the tool for which tool length compensation is selected during runup or
on reset or
part program end as a function of MD20110 $MC_RESET_MODE_MASK, and on part
program start as a function of MD20112 $MC_START_MODE_MASK
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
Machine data
3.3 Channel-specific machine data
Parameter Manual
136 List Manual, 01/2017
