Siemens SINUMERIK 808D

808d-te42 - 50 50 1000 0/0 S
808d-te62 - 50 50 1000 0/0 S
808d-mte40 - 50, 50, 50, 50, 50, 50,
50, 50...
20 1000 7/2 M
808d-mte60 - 50, 50, 50, 50, 50, 50,
50, 50...
20 1000 7/2 M
Description: Defines the number of NC blocks available for NC block preparation. This figure is
determined mainly by the system software and is used largely for optimization.
Approximately 10 Kbytes of dynamic memory is reserved per NC block.
Related to:
MD28060 $MC_MM_IPO_BUFFER_SIZE
(number of NC blocks with IPO buffer)
28081 MM_NUM_BASE_FRAMES C02 M5, K2
- Number of base frames (SRAM) DWORD PowerOn
-
- - 1, 1, 1, 1, 1, 1, 1, 1... 0 16 1/1 M
Description: Number of channel-specific base frames per channel.
The value corresponds to the number of field elements for the predefined field
$P_CHBFR[].
Buffered memory is reserved for this.
28082 MM_SYSTEM_FRAME_MASK C02 M5, K2, W1
- System frames (SRAM) DWORD PowerOn
-
808d-me42 - 0x7A1 0 0x00000FFF ReadOnly S
808d-me62 - 0x7A1 0 0x00000FFF ReadOnly S
808d-te42 - 0x7A1 0 0x00000FFF ReadOnly S
808d-te62 - 0x7A1 0 0x00000FFF ReadOnly S
808d-mte40 - 0x21, 0x21, 0x21,
0x21, 0x21, 0x21,
0x21, 0x21...
0 0x00000FFF 7/2 S
808d-mte60 - 0x21, 0x21, 0x21,
0x21, 0x21, 0x21,
0x21, 0x21...
0 0x00000FFF 7/2 S
Description: Bit mask for configuring channel-specific system frames included in the channel.
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7: System frame $P_ISO1FR for ISO G51.1 Mirror
Bit 8: System frame $P_ISO2FR for ISO G68 2DROT
Bit 9: System frame $P_ISO3FR for ISO G68 3DROT
Bit 10: System frame $P_ISO4FR for ISO G51 Scale
Bit 11: System frame $P_RELFR for relative coordinate systems
Machine data
3.3 Channel-specific machine data
Parameter Manual
List Manual, 01/2017 211
