28083 MM_SYSTEM_DATAFRAME_MASK C02 -
- System frames (SRAM) DWORD PowerOn
-
- - 0xF9F, 0xF9F, 0xF9F,
0xF9F, 0xF9F, 0xF9F,
0xF9F, 0xF9F...
0 0x00000FFF 1/1 S
Description: Bit mask for configuring channel-specific system frames in the data storage (SRAM).
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7: System frame $P_ISO1FR for ISO G51.1 Mirror
Bit 8: System frame $P_ISO2FR for ISO G68 2DROT
Bit 9: System frame $P_ISO3FR for ISO G68 3DROT
Bit 10: System frame $P_ISO4FR for ISO G51 Scale
Bit 11: System frame $P_RELFR for relative coordinate systems
28180 MM_MAX_TRACE_DATAPOINTS EXP, C02, C06 -
- Length of the trace data buffer DWORD PowerOn
NBUP
- - 100, 100, 100, 100,
100, 100, 100, 100...
0 20000 1/1 M
Description: MM_MAX_TRACE_DATAPOINTS defines the size of an internal data buffer which contains the
trace recordings.
28200 MM_NUM_PROTECT_AREA_CHAN C02, C06, C09 A3
- Number of channel-specific protection zones (SRAM) DWORD PowerOn
-
808d-me42 - 10 0 10 1/1 M
808d-me62 - 10 0 10 1/1 M
808d-te42 - 10 0 10 1/1 M
808d-te62 - 10 0 10 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
Description: This machine data defines how many channel-specific protection areas are set up.
Related to:
MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE (number of simultaneously active protection
areas)
MD18190 $MN_MM_NUM_PROTECT_AREA_NCK (number of control-specific protection areas
(SRAM))
References:
/FB/, A3, "Axis/Contour Tunnel Monitoring, Protection Areas"
Machine data
3.3 Channel-specific machine data
Parameter Manual
212 List Manual, 01/2017
