28210 MM_NUM_PROTECT_AREA_ACTIVE C11, C02, C06,
C09
A3
- Number of simultaneously active protection zones in one channel DWORD PowerOn
-
808d-me42 - 10 0 10 1/1 M
808d-me62 - 10 0 10 1/1 M
808d-te42 - 10 0 10 1/1 M
808d-te62 - 10 0 10 1/1 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 10 1/1 M
Description: This machine data defines the number of protection areas that may be activated
simultaneously for each channel.
It is not practical to enter a numerical value greater than MD18190
$MN_MM_NUM_PROTECT_AREA_NCK + MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN.
Related to:
MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN (Number of blocks for channel-specific
protection areas)
MD18190 $MN_MM_NUM_PROTECT_AREA_NCK (Number of control-specific protection areas
(SRAM))
References:
/FB1/ Function Manual Basic Functions; Axis Monitoring, Protection Areas (A3)
28212 MM_NUM_PROTECT_AREA_CONTOUR C11, C02, C06,
C09
A3
- Elements for active protection zones (DRAM) DWORD PowerOn
-
- - 30, 30, 30, 30, 30, 30,
30, 30...
0 50 1/1 M
Description: This machine data defines for each channel how many internal contour elements in total
are held available for active protection zones.
Dynamic memory is used.
The MD affects the memory requirements for the activated protection zones.
This machine data is active only if MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE is not
equal to 0.
28240 MM_NUM_SYNC_DIAG_ELEMENTS N05, C02 -
- Number of diagnostic elements for expressions in synchronized
actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1 M
Description: The values of the variables and machine data during diagnostics of the motion-
synchronous actions are
saved to memory elements for storage in the control. A motion-
synchronous action uses up to the number of elements for as many variables as are set
with MD28241 $MC_MAXNUM_SYNC_DIAG_VAR.
The following are assigned:
● 1 element for each variable
● 1 element for each index
Example:
WHEN $R1 == 1 DO $R2 = $R[AC_MARKER[1]]
R1 = 2 elements, variable with written value 1 element, index "1" an element
R2 = 2 elements, variable with written value 1 Element, index "2" an element
