Description: Number of $AC_SYSTEM_ PARAM parameters for motion-synchronous actions.
Depending on MD28255 $MC_MM_BUFFERED_AC_PARAM, DRAM or SRAM is required.
Reserved for SIEMENS applications.
28276 MM_NUM_AC_SYSTEM_MARKER EXP, C02 -
- Number of $AC_SYSTEM_MARKER for motion-synchronous
actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 20000 1/1 M
Description: Number of $AC_SYSTEM_MARKER markers for motion-synchronous actions.
Depending on MD28257 $MC_MM_BUFFERED_AC_MARKER, DRAM or SRAM is required.
Reserved for SIEMENS applications.
28290 MM_SHAPED_TOOLS_ENABLE C01, C08, C02 -
- Enable tool radius compensation for contour tools BOOLEAN PowerOn
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - ReadOnly M
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/2 M
Description: The function "Tool radius compensation for contour tools" is enabled with this tool.
28300 MM_PROTOC_USER_ACTIVE C02 -
- Activation of logging for a user BOOLEAN PowerOn
-
- 10 TRUE, TRUE, FALSE,
FALSE, FALSE,
TRUE,
TRUE,
TRUE,
FALSE,, T...
0 - 1/1 M
Description: Activation of recording for a user.
The users 0 and 1, and 5 - 9 are reserved for system functions.
The users 2, 3 and 4 can be used by OEM.
Machine data
3.3 Channel-specific machine data
Parameter Manual
List Manual, 01/2017 217
