Siemens SINUMERIK 808D - Page 218

28302 MM_PROTOC_NUM_ETP_STD_TYP C02 -
- Number of standard event types ETP DWORD PowerOn
-
- 10 28, 6, 0, 0, 0, 20, 20,
20, 0, 3, 28, 6, 0, 0, 0,
20, 20, 20, 0,...
28, 6, 0, 0, 0, 20,
20, 20...
61, 61, 61, 61,
61, 61, 61, 61...
1/1 M
Description: Number of standard event types required in the ETP OPI block.
28400 MM_ABSBLOCK EXP, C02 K1
- Activate basic blocks with absolute values DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 512 2/2 M
Description: Value:
0: Basic blocks with absolute values deactivated.
1: Basic blocks with absolute values activated;
A display buffer of the following size is created:
(MD28257 $MC_MM_BUFFERED_AC_MARKER + MD28070 $MC_MM_NUM_BLOCKS_IN_PREP) * 256 bytes
>= 128: Basic blocks with absolute values activated.
28402 MM_ABSBLOCK_BUFFER_CONF EXP, C02 K1
- Setting of upload buffer size DWORD PowerOn
-
- 2 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0...
0 32000 2/2 M
Description: Dimensioning the size of the upload buffer:
MD28402 $MC_MM_ABSBLOCK_BUFFER_CONF[0] : Number of blocks before the current block
MD28402 $MC_MM_ABSBLOCK_BUFFER_CONF[1] : Number of blocks after the current block
The machine data is tested for the following upper / lower limits during startup:
0 <= MD28402 $MC_MM_ABSBLOCK_BUFFER_CONF[0] <= 8
Alarm 4152 is issued when the limits are violated.
28520 MM_MAX_AXISPOLY_PER_BLOCK C02 B1
- Maximal number of axial polynomials per block DWORD PowerOn
-
808d-me42 - 1 1 15 0/0 S
808d-me62 - 3, 3, 3, 3, 3, 3, 3, 3... 1 15 1/1 M
808d-te42 - 1 1 15 0/0 S
808d-te62 - 1 1 15 0/0 S
808d-mte40 - 3, 3, 3, 3, 3, 3, 3, 3... 1 15 0/0 S
808d-mte60 - 3, 3, 3, 3, 3, 3, 3, 3... 1 15 0/0 S
Description: Maximum number of axis polynomials which can be contained in a block.
In the standard case, each block contains only one polynomial per axis, i.e. this data
can be set to 1 immediately.
More polynomials are required in the following cases:
This data must have a value of at least 3 for smoothing with G642 to G645.
A value of 5 is recommended if COMPCAD (Advanced Surface) is used.
A value of 15 is recommended if COMPSURF is used.
Machine data
3.3 Channel-specific machine data
Parameter Manual
218 List Manual, 01/2017
