Siemens SINUMERIK 808D Parameter Manual

0: Local bus (808d, 828d analog spindle)
1: reserved (previously SIMODRIVE611D bus, 1st DCM)
2: reserved (previously local P bus)
3: reserved (previously SIMODRIVE611D-Bus, 2. DCM)
4: reserved (virtual buses)
5: PROFIBUS/PROFINET (e.g. SINUMERIK 840Di)
6: reserved (same effect as 5)
30110 CTRLOUT_MODULE_NR A01, A11 G2, S9
- Setpoint assignment: module number BYTE PowerOn
-
808d-me42 1 1, 2, 3, 4, 5, 6, 7, 8... 1 31 2/2 M
808d-me62 1 1, 2, 3, 4, 5, 6, 7, 8... 1 31 2/2 M
808d-te42 1 1, 2, 3, 4, 5, 6, 7, 8... 1 31 2/2 M
808d-te62 1 1, 2, 3, 4, 5, 6, 7, 8... 1 31 2/2 M
808d-mte40 1 1, 2, 3, 4, 5, 6, 7, 8... 1 31 7/2 M
808d-mte60 1 1, 2, 3, 4, 5, 6, 7, 8... 1 31 7/2 M
Description: In this MD, enter the number of the module within a bus segment through which the
output is addressed.
For an axis on the PROFIBUS/PROFINET, the logical I/O address from MD13050
$MN_DRIVE_LOGIC_ADDRESS[index] is assigned by entering index+1 in MD30110
$MA_CTRLOUT_MODULE_NR.
30120 CTRLOUT_NR EXP, A01 G2
- Setpoint assignment: Setpoint output on drive submodule/module BYTE PowerOn
-
808d-me42 1 1, 2, 3, 4 1 4 2/2 M
808d-me62 1 - 1 4 2/2 M
808d-te42 1 1, 2, 3, 4 1 4 2/2 M
808d-te62 1 - 1 4 2/2 M
808d-mte40 1 1, 2, 3, 4 1 4 2/2 M
808d-mte60 1 - 1 4 2/2 M
Description: Number of the output on a module which is used to address the setpoint output.
The value is always 1 for modular drives.
30130 CTRLOUT_TYPE A01, A11 G2, M3, S9
- Output type of setpoint BYTE PowerOn
-
- 1 0 0 3 2/2 M
Description: The type of speed setpoint output is entered into this MD:
0: Simulation (no HW required)
1: Setpoint output active (differentiation via hardware configuration)
2: Semi servo -only when the hardware is available onboard
3: Reserved
4: Reserved
Machine data
3.4 Axis-specific machine data
Parameter Manual
List Manual, 01/2017 221
