Start = 180 degrees -> modulo range 180 <->540 degrees
Start = -180 degrees -> modulo range -180 <->180 degrees
30350 SIMU_AX_VDI_OUTPUT A01, A06 A2, G2, Z1
- Axis signals output for simulation axes BOOLEAN PowerOn
CTEQ
- - FALSE 0 - 1/1 M
Description: The machine data defines whether axis-specific interface signals are output to the PLC
while an axis is being simulated.
1: The axis-specific NC/PLC interface signals for a simulated axis are output to the
PLC.
This means that the user PLC program can be tested without the drives having to be
available.
0: The axis-specific NC/PLC interface signals for a simulated axis are not output to
the PLC.
All axis-specific NC/PLC interface signals are set to "0".
Not relevant for:
MD30130 $MA_CTRLOUT_TYPE (setpoint output type) = 1
30450 IS_CONCURRENT_POS_AX EXP, A01 G1
- Default for reset: neutral/channel axis BOOLEAN Reset
CTEQ
808d-me42 - FALSE 0 - 0/0 S
808d-me62 - FALSE 0 - 0/0 S
808d-te42 - FALSE 0 - 0/0 S
808d-te62 - FALSE 0 - 0/0 S
808d-mte40 - FALSE 0 - 7/2 M
808d-mte60 - FALSE 0 - 7/2 M
Description: For SW4.3:
If FALSE: On RESET, a neutral axis is reassigned to the NC program.
If TRUE: On RESET, a neutral axis remains in the neutral axis state and an axis
assigned to the NC program becomes a neutral axis
30455 MISC_FUNCTION_MASK A06, A10 R2, S3, R1
- Axis functions DWORD Reset
CTEQ
- - 0x00 0 0x7FFF 1/1 M
Description: Bit 0 = 0:
Modulo rotary axis/spindle: programmed positions must be in the modulo range.
Otherwise an alarm is output.
Bit 0 = 1:
When programming positions outside the modulo range, an alarm is not signaled. The
position is modulo-converted internally.
Example: B-5 has the same significance as B355, POS[A]=730 is identical to POS[A]=10
and SPOS=-360 behaves the same as SPOS=0 (modulo range 360 degrees)
Bit 1 = 0:
Determination of reference point position of rotary, distance-coded encoders analog
(1:1) in relation to the mechanical absolute position.
Bit 1 = 1:
Determination of reference point position of rotary, distance-coded encoders within
the configured modulo range.
Machine data
3.4 Axis-specific machine data
Parameter Manual
List Manual, 01/2017 229
