Bit 10 = 1:
The maximum dynamic performance of a TRAIL or TANGON axis has no effect on the dynamic
path response. This can result in a longer overtravel of the dependent axis.
Bit 11 = 0:
Deactivation of the CP software limit monitoring
Bit 11 = 1:
Activation of the CP software limit monitoring for the following slave axes/spindles:
- coupling, type CP with CPSETTYPE[FAx] = "CP"
- coupling, type CP, TRAIL, EG, LEAD, or COUP with a maximum of one active master axis/
spindle
Bit 12 = 0:
When resetting the control enable of the stationary axis/spindle (in respect of this
master axis/spindle), you must always switch over to actual value coupling, just as
for a fast stop after resetting the control enable during motion (alarm 21612). This
applies to generic couplings (with replacement cycles or for CP programming).
Bit 12 = 1:
When resetting the control enable of the stationary axis/spindle (in respect of this
master axis/spindle), changeover to actual value coupling is inhibited. This applies
to generic couplings (with replacement cycles or for CP programming).
Bit 13 = 0:
An axis-specific DRIVE setting by means of MD35240 $MA_ACCEL_TYPE_DRIVE[] or by
programming
DRIVEA() of
an axis is ignored by the path dynamic response if the relevant
axis is interpolated with the path.
Bit 13 = 1:
An acceleration characteristic of an axis activated by MD35240 $MA_ACCEL_TYPE_DRIVE[]
or by programming of DRIVEA() is taken into account when defining the path dynamic
response if the relevant axis is interpolated with the path.
Bit 14 = 0:
During cartesian PTP traversing, the "shortest path" strategy for
software limit crossing of a rotary axis is retained.
Bit 14 = 1:
The "long path" strategy for avoiding the software limit crossing is
used if a rotary axis were to cross the software limit switch during cartesian PTP
traversing with the "shortest path" strategy.
30460 BASE_FUNCTION_MASK A01 K5, P2, P1
- Axis functions DWORD PowerOn
CTEQ
- - 0x00 0 0x3FF 1/1 M
Description: Axis-specific functions can be set using this MD.
The MD is bit-coded; the following bits are assigned:
Bit 0 = 0:
"Axis control" is not permissible.
Bit 0 = 1:
"Axis control" is permissible (the axis moves in the speed mode, if the NC/PLC
interface signal DB380x DBX5000.1 (Axis control) is set).
Bit 1:
Reserved for "Axis control".
Bit 2 = 0:
Axis-specific diameter programming not permitted.
Bit 2 = 1:
Axis-specific diameter programming permitted.
Machine data
3.4 Axis-specific machine data
Parameter Manual
List Manual, 01/2017 231
