Bit 3:
Reserved for "Axis control".
Bit 4 = 0:
For control purposes, the axis can be used by NC and PLC.
Bit 4 = 1:
The axis is exclusively controlled by the PLC.
Bit 5 = 0:
The axis can be used by the NC and PLC.
Bit 5 = 1:
The axis is a permanently assigned PLC axis. However, the axis can be jogged and
referenced.
Axis exchange between channels is not possible. The axis cannot be assigned to the NC
program.
Bit 6 = 0:
The channel-specific interface signal DB3200 DBX6.0 (feedrate disable) has an effect
on the axis, even though it is a PLC-controlled axis.
Bit 6 = 1:
The channel-specific interface signal DB3200 DBX6.0 (feedrate disable) has no effect
on the axis, if it is a PLC-controlled axis.
Bit 7 = 0:
The channel-specific interface signal DB3300 DBX4.3 (all axes stationary) is set
dependent on the axis, even though it is PLC-controlled.
Bit 7 = 1:
The channel-specific interface signal DB3300 DBX4.3 (all axes stationary) is set
independent of the axis, if this axis is PLC-controlled..
Bit 8 = 0:
The axis is an 'interpolating (full) axis' (path/GEO/additional path axis/GEOAX()/
spindle for thread cutting/tapping)
Bit 8 = 1:
The axis is a positioning axis / auxiliary spindle
Bit 9 = 0:
The PRESETON is enabled. PRESETONS is inhibited.
Bit 9 = 1:
The PRESETON is inhibited. PRESETONS is enabled.
30465 AXIS_LANG_SUB_MASK N01 K1
- Substitution of NC language commands DWORD PowerOn
-
- - 0x0 0x0 0xF 1/1 M
Description: MD30465 $MA_AXIS_LANG_SUB_MASK defines for the leading spindle(s) of a coupling
(synchronous spindle coupling,
electronic gear, coupled motion, master value coupling,
master-slave) which language constructs/functions are to be substituted by the user
program set by MD15700 $MN_LANG_SUB_NAME / MD15702 $MN_LANG_SUB_PATH (default: /
_N_CMA_DIR/_N_LANG_SUB_SPF).
The substitution is executed only if a coupling is active for the relevant spindle and,
in the case of a gear stage change, only if a gear stage change is actually pending.
Bit 0 and bit 1 are relevant for the axis coupling types: synchronous spindle coupling,
electronic gear, coupled motion and master value coupling.
Bit 2 and bit 3 are relevant for the master-slave coupling
Bit 0 = 1:
Axis coupling: Automatic (M40) and direct (M41-M45) gear stage change
Bit 1 = 1:
Machine data
3.4 Axis-specific machine data
Parameter Manual
232 List Manual, 01/2017
