[encoder no.]: 0 or 1
31080 DRIVE_ENC_RATIO_NUMERA A02, A11 A3, G2, S1
- Numerator measuring gearbox DWORD PowerOn
-
- 1 1, 1 1 2147000000 2/2 M
Description: The measuring gearbox numerator is entered in this MD.
The index [n] of the machine data has the following coding:
[encoder no.]: 0 or 1
31090 JOG_INCR_WEIGHT A01, A12 H1, G2
mm, degrees Evaluation of an increment with INC/handwheel DOUBLE Reset
CTEQ
- 2 0.001, 0.00254 - - 2/2 M
Description: The value entered in this MD defines the path of an increment which applies when an
axis is traversed with the JOG keys in incremental mode or with the handwheel.
The path traveled by the axis on each increment each time the traversing key is pressed
or for each handwheel detent position is defined by the following parameters:
● MD31090 $MA_JOG_INCR_WEIGHT
(Weighting of an increment of a machine axis for INC/handwheel)
● Selected increment size (INC1, ..., INCvar)
The possible increment stages are defined globally for all axes in MD11330
$MN_JOG_INCR_SIZE_TAB [n] and in SD41010 $SN_JOG_VAR_INCR_SIZE.
Entering a negative value reverses the direction of evaluation of the traverse keys
and the handwheel rotation.
Related to:
MD11330 $MN_JOG_INCR_SIZE_TAB
SD41010 $SN_JOG_VAR_INCR_SIZE
31092 JOG_INCR_WEIGHT_TRAFO A01, A12 H1, G2
mm, degrees Evaluation of an increment for INC/handwheel for active
transformation
DOUBLE Reset
CTEQ
- 2 0.0, 0.0 - - 2/2 M
Description: The input value is used to define the distance of an increment which, when traversing
an axis during
active transformation using the JOG keys, is valid for the incremental
dimension or via handwheel.
The distance, through which the axis traverses when executing the incremental
dimension with transformation active, depending on the traversing key actuated or
handwheel grid position, is defined by the following parameters:
● MD31092 $MA_JOG_INCR_WEIGHT_TRAFO
(Evaluating an increment of a machine axis for INC/handwheel)
● selected increment size (INC1, ..., INCvar)
The possible increment steps are globally defined for all axes in MD11330
$MN_JOG_INCR_SIZE_TAB [n] or in SD41010 $SN_JOG_VAR_INCR_SIZE.
Entering a negative value reverses the direction evaluation of the traversing keys and/
or the handwheel direction of rotation.
The set value is only effective, if this is > 0 ist. For values of zero, then MD31090
$MA_JOG_INCR_WEIGHT is effective
Corresponds with:
MD11330 $MN_JOG_INCR_SIZE_TAB
MD31090 $MA_JOG_INCR_WEIGHT
