SD41010 $SN_JOG_VAR_INCR_SIZE
31100 BERO_CYCLE A02, EXP, A01 G2
- Steps for rotation monitoring DWORD PowerOn
CTEQ
808d-me42 1 10000, 10000, 10000, 0 0 10000000 1/1 M
808d-me62 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 0/0 S
808d-te42 1 10000, 10000, 10000, 0 0 10000000 1/1 M
808d-te62 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 0/0 S
808d-mte40 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 1/1 M
808d-mte60 1 2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000, 2000,
2000, 2000...
10 10000000 0/0 S
Description: Repetition cycle from BERO in steps
31110 BERO_EDGE_TOL A02, A01, A12 H1, G2
- Step tolerance for rotation monitoring DWORD NEW CONF
CTEQ
808d-me42 1 4000, 4000, 4000, 0 0 10000000 1/1 M
808d-me62 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 0/0 S
808d-te42 1 4000, 4000, 4000, 0 0 10000000 1/1 M
808d-te62 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 0/0 S
808d-mte40 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 1/1 M
808d-mte60 1 50, 50, 50, 50, 50, 50,
50, 50, 50, 50, 50, 50,
50, 50, 50, 50...
10 10000000 0/0 S
Description: BERO edge tolerance in steps
31122 BERO_DELAY_TIME_PLUS A02, A06 S1, R1
s BERO delay time Plus DOUBLE NEW CONF
-
- 1 0.000110, 0.000110 0.0 - 2/2 M
Description: This machine data in combination with the setting in MD34200 $MA_ENC_REFP_MODE
(referencing mode) =
7 causes a signal runtime compensation in the positive direction
of movement at a position determined by a BERO (zero mark).
The typical total delay time of the BERO message path for overtravel in the positive
direction of movement is entered.
Machine data
3.4 Axis-specific machine data
